1. This machine is designed and produced based on high quality, high speed, high efficiency, reliability and safety, with the advantages of quick changing order and easy operation.

2. Adapting imported PLC with touch screen control. It can save order, and accelerate the changing order speed.

3. Adopt high quality material and assembly part.

4. All cylinders and rollers are chrome plated for ideal hardness.

5. Transmission gears from precision grinded alloy steel and with spraying type circulating lubrication system.

6. Use expansion sets tight link to reduce abrasion of the shaft, keep high precision of the machine in long year.

7. Adopt hanging structure, auto reset, quick changing order.

8. Each unit is equipped with Emergency Stop switch to ensure safety operation.

9. Using Self Locking gap adjustment device for ease operation.

10. Electric element, bearing, and pneumatic element all use international famous brand.

11. Mechanical lead edge feeder system,inverter adjust air volume,feeding is precision and steady.

12. The slot knife with phasing and box height adjustment device, the frequency changer control the dynamic 360 degree adjustment.

13. The slot knife seat lateral movement uses the electric control, in fast and accurate.

14. Rubber roller automatic displacement device,prolong the service life .

15. Quick replacement rubber anvil is from abroad,it is easy for replacement and wear-proof.

16. Pull roller puick lateral moving mechanism.

17. Equipped with automatic paper stacking machine.

Model		RYKC18	RYKC22	RYKC25
Max machine speed		120pcs/min	100pcs/min	100pcs/min
Max feeding size		1880x3200mm	2260x3400mm	2570x3600mm
Skip feeding size		2200x3200mm	2700x3400mm	3100x3600mm
Max printing area		1800x3200mm	2200x3400mm	2500x3600mm
Min feeding size		500x890mm	550x890mm	600x890mm
Max slotting depth		490mm	580mm	660mm
Registration precision		2.5-12mm
Printing plate thickness		≤±0.6mm
Paper thickness		6mm
Min slotting interval	Normal	190x190x190x190mm
	Reverse	310x110x310x110mm
