1. The machine adopts strengthened single-side driving system, for steady running and easy maintenance.

2. The motor adopts infinitely variable speed drive with power saving.

3. The machine adopts double face tooth rod for operation. Up and down linkage makes adjustment in place, precise and rapid.

4. Delivery equips several thick belts with shaking motor to ensure paper feeding in continuous, exact and automatic.

5. It has a grinder in each side, which makes the glue more stable, firmly.

6. It offers two groups of gluing bucket up and down for vertical adjustment, while teeth rods for horizontal adjustment.

7. It equips touch screen, PLC controller, photo-electric counting, automatic sheet kicker.

8. Conveyor part is equipped with sponge belt.

9. In the pre-folding part, the firs fold and the third fold can be exchanged by 180 degree or 90 degree. The second fold and the fourth fold can be molded in 180 degree; the special design is also available.

Line speed	200m/min
Suitable paper	350-800 g/ms, paperboard
Box forming	4/6corner box, bottom-lock, straight line box, double walls box
Fold method	1st & 3rd folds 90°, 2nd & 4th folds 180°
Power	13.2kw
Dimension	12100x1500x1500mm
Weight	5100kg
