1. The feeder in this machine adopts back-push feeding system, which is controlled pneumatically, and its structure is simple and reasonable.

2. The width between stacker and feeding table is adjusted concentrically in the centre. The operation is very easy without error.

3. New designed copper scraper cooperates with the glue roller more compactly, effectively avoiding paper winding. And it is much more durable.

4. Adopt imported ultrasonic paper tester device, simple operation which can keep two pieces of layered paper from entering into the machine at the same time.

5. The cardboard feeding table is controlled by linear guide line and servo motor, its location is correct and quick.

6. In the cardboard feeding table, the machine can automatically stop when lack of paper to reduce rejection rate.

7. Conveyor belt is equipped with a powerful vacuum fan to keep the paper without any movement.

8. Paper feeding and positioning system adopts imported high-precise photoelectric control device to make the paper and cardboard location more accurate.

9. The folding unit adopts servo motor, no displacement and no scratches.

10. Pneumatic pressure control for folding, concentric shaft adjustment for angle repair, easy to operate; it also adopts a new technology on the folding way which solves the problem of irregular covers.

11. The whole machine adopts PLC control, featuring in simple operation. The troubles are displayed directly on the screen, which helps the operator easily remove them.

12. Low electricity consumption, low noisy and easy adjustment.

Paper size	Max.570x1030mm Min.130x230mm
Paper thickness	100-200g/m2
Cardboard thickness	1-3mm
Finished product size	Max.540-1000mm Min.100-200mm
Spine	10mm
Folded paper size	10-18mm
Max cardboard quantity	6pieces
Precision	±0.50mm
Production speed	≦25sheets/min
Motor power	11kw 380v 3phase
Heater power	12kw
Air supply	10L/min 0.6Mpa
Weight	3900kg
Dimension	8500x2300x1700mm
